A) It possesses all the functions of a conventional lathe and also incorporates some of the functions of a CNC lathe.
B) The large screen provides an intuitive display. It has both Chinese and English interfaces. The input is simple and the operation is extremely convenient.
C) X and Z axes can perform fixed-length processing, manual feed, automatic feed, and rapid movement.
D) The real-time dynamic display of processing process operating parameters is available. It also has the function of constant linear speed cutting.
E) It can achieve processing of various types and any pitch of threads.
F) Servo motor drive, with a wide speed range.
G) Centralized transmission, featuring a mechanical structure capable of meeting the requirements of low-speed and high-torque cutting.
H) The high-precision spindle bearing structure can meet the requirements of various cutting processes and precision levels.
I) The bed material is high-strength cast iron, and the guide rails are processed by surface hardening and precision grinding, which makes them extremely durable.
J) The appearance is beautiful and simple, the layout is reasonable, and the safety protection and functional accessories are complete.
| ltems | Parameters | Unit | CD6150 |
| Capacity | Swing over bed | mm | 500 |
| Swing over carriage | mm | 290 | |
| Center height | mm | 250 | |
| Max. workpiece length | mm | 1000/1500/2000/3000 | |
| Max. processing length | mm | 950/1450/1950/2920 | |
| Bed width | mm | 400 | |
| Spindle | 3-jaw chuck diameter | mm | 250 |
| Speed ranges | Stepless | ||
| Speeds | rpm | 16-1600 | |
| Spindle bore | mm | 82 | |
| Spindle taper | mm | Metric90 | |
| Spindle nose | C8 | ||
| Slides | Top slide travel | mm | 150 |
| Cross travel (X axis) | mm | 260 | |
| Longitudinal travel(Z axis) | mm | 1000/1500/2000/3000 | |
| Toolpost | Number of stations | 4 | |
| Tool shank Size | mm | 25×25 | |
| Tailstock | Movement | manual | |
| Quill travel | mm | 160 | |
| Quill diameter | mm | 75 | |
| Quill taper | MT5 | ||
| Feed | Rapid (Z/X axes) | mm/min | 3000/1500 |
| X Cross feed (X axis) | mm/min | 15-1000 | |
| Longitudinal feed (Z axis) | mm/min | 30-3000 | |
| Movement per rotation /grade of top slide handwheel | mm/mm | 5/0.1 | |
| Movement per rotation /grade of cross slide handwheel (Xaxis) | mm/mm | 5/0.02 | |
| Movement per rotation/grade oflongitudinal slide handwheel (Z axis) | mm/mm | 30/0.1 | |
| Threads | Metric threads | mm | 0.25-24 |
| Inch threads | in | 0.01-1 | |
| Modular threads | mm | 0.08-8 | |
| Diametrical threads | in | 0.01-0.32 | |
| Motor | Servo spindle motor | kW | 7.5 |
| Feed servo motor power | kW | 1.5 | |
| Drive belt | Type | XPA2282 | |
| Quantity | Pcs | 5 | |
| Others | Length | mm | 2430/2930/3430/4430 |
| Width x Height | mm | 1145 ×1740 | |
| Weight | kg | 2130/2280/2430/2880 |
Quality Assurance:
Focus on “Customer experience” and “Fast Service”, adhere to the use of first-line brand components, committed to building a first-class design, manufacturing and service system is Samson CNC product quality definition, in order to achieve stable and reliable product quality, we in procurement, design, manufacturing, inspection, logistics and other aspects of the establishment of standards, strictly control every step to ensure product quality. Zero tolerance for shoddy manufacturing.
After-sales Service:
Dear users, thank you for purchasing Shandong Shansen CNC Technology Co. , Ltd. . Products!
If you find any abnormality after purchase or during use, please contact the manufacturer directly. We will strictly implement 3 power 48(3 hours to solve the problem with customers within 48 hours, such as the phone can not be solved within 48 hours to reach the user site) to better provide customers with efficient quality and efficient service, and accept the supervision of the majority of users. Warranty period, free maintenance, the product quality problems caused by the replacement of spare parts, I provide free quick replacement.
The ADJUSTER team will provide you with high-quality and thoughtful service and win your trust and praise with excellent technology and cordial attitude.
